ELS100-24TXG User Interface 43
Port Menu
The Port Menu allows you to display information for each port in a table
format, as well as to access the Port Configuration Menu. You can also
refresh the screen information. Select c from the Main Menu to view the
Port Menu. Figure 3-17 shows the Port Menu and the accompanying table
describes the Port Menu.
Figure 3-17. Port Menu
PORT MENU Access Control: READ/WRITE
LINK
AUTO
FULL
PORT FLOW
ID PORT NAME ENABLED
STATUS
NEGOTIATED DUPLEX SPEED TYPE CONTROL
---------------------------------------------------------------------------------------------------------------------------------------
1
Yes
CONNECTED
No
Yes
100
100TX
No
2
Yes
CONNECTED
No
Yes
100
100TX
No
3
Yes
CONNECTED
No
Yes
100
100TX
No
4
Yes
CONNECTED
No
Yes
100
100TX
No
5
Yes
CONNECTED
No
Yes
100
100TX
No
6
Yes
CONNECTED
No
Yes
100
100TX
No
7
Yes
CONNECTED
No
Yes
100
100TX
No
8
Yes
CONNECTED
No
Yes
100
100TX
No
9
Yes
CONNECTED
No
Yes
100
100TX
No
10
Yes
CONNECTED
No
Yes
100
100TX
No
11
Yes
CONNECTED
No
Yes
100
100TX
No
12
Yes
CONNECTED
No
Yes
100
100TX
No
n. Next Page
p. Previous Page
f. First Page l. Last Page
r. Refresh
c. Configure
x. Previous Menu
Enter Selection:
Field
Description
ID
The number assigned to the port.
Port Name
The administrative name assigned to the port (1-14 character range).
Enabled
The current “enabled” state of the port, either “Yes” or “No.”
Link Status
The current link state of the port, either “Connected” or “Disconnected.”
Auto
Negotiated
The current state of auto-negotiation for the port, whether or not it has
completed auto-negotiation, either “Yes” or “No”.
Full Duplex
The current full duplex state of the port, either “Yes” or “No.”
Speed
The current speed of the port, either 10Mbps, 100Mbps, or 1000Mbps.
Type
Current connection type: 10T=10Base-T, 100T=100Base-TX,
1000SX=1000Base-SX, 1000LX=1000Base-LX, 1000CX=1000Base-CX.
Flow Control
The current enable/disable flow control port state, either “Yes” or “No.”
Selection
Description
Next Page
Displays the next page of the table.
Previous Page
Displays the previous page of the table.
First Page
Displays the first page (top) of the table.
Last Page
Displays the last page of the table.
Refresh
Refreshes the screen to reflect latest system conditions.
Configure
Opens up the Port Configuration Menu. From this menu you can configure
an individual port or multiple ports (See Section 4).
