9032947 ELS100-24TXG User Interface 39
VLAN #n Configuration Menu
The VLAN #n Configuration Menu allows you to configure a name for a
specific VLAN, add or remove a port in the VLAN, and add or remove an
egress port in the VLAN. Select c from the VLAN Menu to view the VLAN
#n Configuration Menu. Figure 3-13 shows the VLAN #n Configuration
Menu and the accompanying table describes the VLAN #n Configuration
Menu.
Figure 3-13. VLAN #n Configuration Menu
1. The designation “#n” represents the number of the
specific VLAN to be configured.
2. When configuring ports using the Ports in VLAN pa-
rameter, they will be moved to that selected VLAN, and
automatically removed from their previous VLAN.
VLAN #n CONFIGURATION Access Control: READ/WRITE
Ports in VLAN 1-26
VLAN Egress Ports None
a. VLAN Name default
b. Add Port in VLAN
c. Remove Port In VLAN
d. Add VLAN Egress Port
e. Remove VLAN Egress Port
x. Previous Menu
Enter Selection:
Field Description
Ports in VLAN Lists the ports in the specific VLAN.
VLAN Egress Ports Lists the VLAN Egress Ports for the specific VLAN.
Selection Description
VLAN Name Allows you to enter an administrative name for the
VLAN (1-14 character range; entering a VLAN
name is not required).
Add Port in VLAN Allows you to enter a port in the VLAN.
Remove Port in VLAN Allows you to remove a port in the VLAN.
Add VLAN Egress Port Allows you to add a VLAN Egress Port.
Remove VLAN Egress Port Allows you to remove a VLAN Egress Port.
