34 ELS100-24TXG User Interface ELS100-24TXG
Spanning Tree Configuration Menu (continued)
Selection Description
Spanning Tree Protocol
Enable Allows you to enable (Yes) or disable (No) the
global Spanning Tree operation on the switch.
Port Configuration Menu Provides access to the Spanning Tree Port Con-
figuration Menu.
Hello Time (seconds) The time interval between the sending of Config-
uration BPDUs by the bridge, if it is root (1-10
second range).
Forward Delay (sec-
onds) The time interval delay before a port transfers
into the forwarding state, if it is root (4-30 second
range).
Max Age (seconds) The maximum age of received protocol informa-
tion before it is discarded (6-40 second range).
Bridge Priority A relative priority of bridges, with the lowest val-
ue bridge ID indicating the highest priority (0-
65535 range).
