YSI IQ SensorNet ViSolid Sensor 700 IQ - Manual (Page 53)

ViSolid
®
700 IQ (SW) Indexes
ba76040e04 05/2014 8 - 3
8.2 Status info
The status info is a piece of coded information about the current state
of a sensor. Each sensor sends this status info to the controller. The
status info of sensors consists of 32 bits, each of which can have the
value 0 or 1.
Status info,
general structure
The bits 0 - 15 are reserved for general information.
The bits 16 - 21 are reserved for internal service information.
You obtain the status info:

via a manual query in the menu, Einstellungen/Setup/Service/List of
all components
(see system operating manual)
 via an automated query
– of a superordinate process control (e. g. when connected to the
Profibus)
– of the IQ Data Server (see operating manual of the
IQ S
ENSOR
N
ET software pack)
ViSolid
®
700 IQ (SW)
Status info
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (general)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (internal)
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
The evaluation of the status info, e.g. in the case of an auto-
mated query, has to be made individually for each bit.
Status bit Explanation
Bit 0 Component hardware defective
Bit 1 SensCheck: Measurement interfered
Bit 2 SensCheck: Ultrasound cleaning system has
failed
Bit 3-31 -
