YSI IQ SensorNet ViSolid Sensor 700 IQ - Manual (Page 26)

3 - 14 ba76040e04 05/2014
Commissioning ViSolid
®
700 IQ (SW)
TSS measuring
mode:
Menu selection:
User calibration  Basic settings
 Value pairs 1..3
 Value pairs 4..6
 Value pairs 7..8
Selection between the use of the basic set-
tings and the entry of calibration value pairs.
For the selection of the value pairs, fields
open for the entry of the values
TSS value 1
to TSS value 8.
and the individual values
SiO2 value 1
to SiO2 value 8.
Starting with TSS value 1, determine and
enter the content of total suspended solids in
mg/l TSS, and, in the case of SiO2 value 1,
enter the related measured SiO2 value.
The input precision is 1 mg/l in each case.
Note:
The values must be entered in descending
order.
If this sequence is not kept to, a calibration
error is displayed after leaving the menu. All
the entered values become invalid.
TSS measuring
mode:
Measuring ranges
The setting
AutoRange =
automatic change-
over of the measur-
ing range
can be selected in all
measuring modes.
 0 ... 400.0 mg/l
 0 ... 4000 mg/l
 0 ... 25000 mg/l Measuring range for the measuring mode
Mtrx.type1:mg/l TSS
 0 ... 400.0 ppm
 0 ... 4000 ppm
 0 ... 2.500 % Measuring ranges for the
Matrix type1:% TSS
measuring mode
 0 ... 4000 mg/l
 0 ... 40000 mg/l Measuring ranges for the
Mtrx.type2:mg/l TSS
measuring mode
 0 ... 4000 ppm
 0 ... 4.000 %
 0 ... 40.00 %
 0 ... 100.0 % Measuring ranges for the
Matrix type2:% TSS
measuring mode
Setting Selection/values Explanation
