ViSolid
®
700 IQ (SW) Technical data
ba76040e04 05/2014 7 - 3
7.3 General data
Dimensions (in mm)
Weight (without sensor
connection cable)
Connection technique Connection using SACIQ (SW) sensor connection cable
Material
* Stainless steel can be susceptible to corrosion at chloride concentra-
tions of ≥ 500 mg/l and more. We recommend to use SW sensors for
applications in such test solutions.
Material
365
Socket SACIQ...
Socket SACIQ...
59.5
40.0
40.0
204
32
ViSolid 700 IQ SW:
ViSolid 700 IQ (H):
365
ViSolid
®
700 IQ (H)
approx. 990 g
VisoTurb
®
700 IQ SW approx. 1420 g
Shaft:
– ViSolid
®
700 IQ (H)
– ViSolid
®
700 IQ SW
V4A stainless steel 1.4571 *
POM
Sensor head:
– ViSolid
®
700 IQ (H)
– ViSolid
®
700 IQ SW
V4A stainless steel 1.4571 *
Titanium
Measurement window
Sapphire
Plug head connector housing POM
Plug, 3-pole ETFE (blue) Tefzel
®
Shaft V4A stainless steel 1.4571 *
