Entering the Calibration
data
Below the smallest value, the calibration curve is extended
to the zero point and, above the largest value, it is extended
to the end of the measuring range.
9
Check the form of the calibration curve.
If the calibration curve corresponds to form 3,
change the conditions at the measuring location and deter-
mine the calibration values again or
do not carry out any measurements in the range below the
turning point (A).
10
In measuring mode with matrix type 1:
If individual calibration values lie outside the measuring range,
change the conditions at the measuring location and deter-
mine the calibration values again or
select measuring mode for matrix type 2
The entry of calibration values that exceed the measuring
range leads to a calibration error. The size of the measuring
range is dependent on the selected measuring mode
(matrix type) (see section 3.5.3).
11
Switch to the setting table of the TSS sensor.
12
Change to the Calibration data menu with <> and
.
13
Select the User calibration menu item with <> and
.
14
Select the Menu selection menu item with <> and
.
15
Select the Value pairs 1..3 menu item with <> and
.
For examples of valid value pair data, see section 4.2.2. A
maximum of 8 value pairs can be entered for the User cal-
ibration
.
16
Select the TSS value 1 menu item with <> and
