8

Input Network Variables (nvi’s) Description


Parameter Variable

Name Function

Room
Temperature

network input
SNVT_temp_p
nviSpaceTemp

This input network variable provides a network remote temperature

value to the thermostat. When linked of written to, the internal
temperature reading (internal sensor) is no longer used.

Valid Range: 40 to 122°F (-40 to 50°C)
Default Null (release) Value: 621.81°F (327.67°C or 0x7FFF)
This network variable is subject to the Receive HeartBeat Time,

nviRcvHrtBt.

Outdoor Air
Temperature

network input
SNVT_temp_p
nviOutdoorTemp

This input network variable provides outdoor air temperature

information to the thermostat from a network value temperature
value. The device will automatically display the value on its display
when linked.

Valid Range: 40 to 122°F (-40 to 50°C)
Default Null (release) Value: 621.81°F (327.67°C or 0x7FFF)

Occupied
Cool & Heat
Setpoints

network Input
SNVT_temp_p
nviSetpoint

This input network variable is used to allow the occupied

temperature setpoints only to be changed via the network from a
single analog value. (Note: the Stand-By and Unoccupied setpoints
are not changed). The corresponding heating and cooling values
are derived from the minimum deadband configuration value

Default Null Value: 621.81°F (327.67°C or 0x7FFF)
Ex. If the minimum deadband configuration value = 2 °F and

nviSetpoint = 70°F.

• The resulting Occupied heating setpoint will equal 69 °F which is

derived from 70 °F minus ½ the minimum deadband configuration
value of 2 °F

• The resulting Occupied cooling setpoint will equal 71 °F which is

derived from 70 °F plus ½ the minimum deadband configuration
value of 2 °F

Room
Humidity

network input
SNVT_lev_percent
nviSpaceRH

This input network variable is the measured room humidity in

percent monitored by the thermostat.

Valid Range: 5 to 90%
Default Null Value: +163.835 (0x7FFF)
This network variable is subject to the Receive HeartBeat Time,

nviRcvHrtBt
