15


Parameter Variable

Name Function

This configuration property defines the thermostat’s common

configuration parameters and their settings.

Valid Range and Default values:

Sub

Name

Valid Range

Default value

01

password

0 to 1000

0

02

control type

0 = On/Off Control
1 = Floating Control

0 = On/Off
Control

03

floating actuator time

0.5 to 9 minutes (0.5
increments)

1.5 minutes

04

cycles per hour

3, 4, 5, 6, 7 and 8
CPH

4 CPH

05

reverse or direct acting
output

0 = Direct Acting (DA)
1 = Reverse Acting
(RA)

0 = Direct
Acting (DA)

06

temperature scale

0 = °C
1 = °F

°F

07

auto mode

0 = Not Active
1 = Active

1 = Active

08

temperature scale

0 = °C
1 = °F

°F

09

pipes number main out
config

2 = 2 pipe
4 = 4 pipe

4 pipe

10 sequence

of

operation

0 = Cooling Only
1 = Heating Only
2 = Cooling & Reheat
3 = Heating & Reheat
4 = Cooling/Heating 4
pipes
5 = Cooling /Heating
4 pipes & Reheat

1 = Heating
Only

11

fan menu

0 = Low-Med-High
1 = Low-High
2 = Low-Med-High-
Auto
3 = Low-High-Auto
4 = On-Auto

4 = On-Auto

12 heat

maximum

setpoint

40 to 90°F
(4.5 to 32°C)

90°F (32°C)

13 cool

minimum

setpoint

54 to 100°F
(12 to 37.5°C)

54°F (12°C)

14

calib room sensor

± 5°F (±2.5°C)

0°C

15

deadband

2, 3, 4 or 5 °F
(1 to 2.5°C)

2°F (1°C)

16

setpoint type

0 = Permanent
1 = Temporary

0

17

setpoint function

0 = Dual Setpoints
1 = Attached
Setpoints

0 = Dual
Setpoints

Thermostat
Common
Configuration
Parameters

network input config


UNVT_cfg_1_fcu_zn

nciCfg1FcuZn

18

temporary occ time

0, 1, 2, 3, up to 24
hours

2 hours
