11


Parameter Variable

Name Function

This network variable input is used to coordinate the Space

Comfort Controller with any node that may need to control the
heat/cool changeover of the unit. This input is overridden by
nviApplicMode, unless nviApplicMode is HVAC_AUTO. If
nviApplicMode is HVAC_AUTO, then nviHeatCool determines the
effective mode of the unit.

Default Null Value: HVAC_AUTO.
This network variable is subject to the receive heartbeat time,

nciRcvHrtBt

Valid Range:

0 = HVAC_AUTO
1 = HVAC_HEAT
2 = HVAC_MRNG_WRMUP – Not Used
3 = HVAC_COOL
4 = HVAC_NIGHT_PURGE – Not Used
5 = HVAC_PRE_COOL – Not Used
6 = HVAC_OFF
7 = HVAC_TEST – Not Used
8 = HVAC_EMERG_HEAT – Not Used
9 = HVAC_FAN_ONLY – Not Used
12 = HVAC_MAX_HEAT – Not Used

Sequence of
operation

network input
SNVT_hvac_mode
nviHeatCool

1

See note 1 below

0xFF = HVAC_NUL – Not Used

This network variable input is used to enable or disable user

access to thermostat

Default Null Value: Level 0.
Valid Range:

Level Occupied

Temperature

Setpoints

System

Mode

Settings

Fan Mode

Settings

Unoccupied

Override

0

Yes access

Yes access

Yes access

Yes access

1

Yes access

Yes access

Yes access

No access

2

Yes access

No access

No access

Yes access

3

Yes access

No access

No access

No access

4

No access

No access

No access

Yes access

Remote
Lockout

network input
SNVT_count
nviRemLockout

5

No access

No access

No access

No access

This network variable input is used to enable or disable

dehumidification

Default Null Value: Dehumidification not allowed
Set value to 100% for both On & Off state
Valid Range:

State =0 = Dehumidification not allowed
(Thermostat’s default value)

Dehumidificati
on Lockout

network input
SNVT_switch
nviDhumiLCK

State = 1 = Dehumidification allowed

This network variable input is used remotely command the

Auxiliary Output (BO5).
NOTE Auxiliary Contact configuration NEEDS to be set to 5 for this
function to operate ( 5 = Output to follow secondary network
occupancy command )

Set value to 100% for both On & Off state
Default Null Value: Auxiliary contact Off
Valid Range:

State = 0 = Auxiliary contact Off (Thermostat’s default value)

Auxiliary
Contact
Remote
Control

network input
SNVT_switch
nviAuxOut


State = 1 = Auxiliary contact On
