12



Output Network Variables (nvo’s) Description


All output network variables will be updated no faster than the Minimum Send Time (nciMinOutTm) configuration
value.
An output network variable will be transmitted immediately when its value has changed significantly
(manufacturer’s defined). Additionally, this variable will also be transmitted as a heartbeat output on a regular
basis as dictated by the Maximum Send Time (nciSndHrtBt) configuration value.

Parameter Variable

Name Function

Room
Temperature

network output
SNVT_temp_p
nvoSpaceTemp

This output network variable is used to monitor the effective space

temperature sensor that the Space Comfort Controller is using for
control. This output echoes the value of the input.

Valid Range: 14 to 122°F (-10 to 50°C)
The value 621.07°F (327.67°C or 0x7FFF) will be sent as an

invalid value in case of a sensor failure.

Supply
Temperature

network output
SNVT_temp_p
nvoDischAirTemp

This output network variable is used to monitor the temperature of

the air that leaves the Space Comfort Controller
NOTE: UI3 needs to be configured to (SS) Supply air sensor
monitoring

Valid Range: -40 to 122°F (-40 to 50°C)
The value 621.81°F (327.67°C or 0x7FFF)will be sent as an invalid

value in case of a sensor failure.

Room
Humidity

network output
SNVT_lev_percent
nvoSpaceRH

This output network variable indicates the space humidity in

percent.

Valid Range: 0 to 100%.
The value 0x7FFF = +163.835% will be set as an invalid value to

indicate a humidity sensor failure.

This output network variable is used to indicate the actual

occupancy mode of the unit. This information is typically reported
to a supervisory controller or provided to another Space Comfort
Controller to coordinate the operation of multiple units

Valid Range:

0 = OC_OCCUPIED
1 = OC_UNOCCUPIED
2 = OC_BYPASS

1

Effective
Occupancy

network output
SNVT_occupancy
nvoEffectOccup

3 = OC_STANDBY


Note 1: OC_BYPASS can be initiated by either nviOccManCmd or a
local input. NvoEffectOccup will only be in OC_BYPASS for the
duration of the ToccTime (nciGenOpts), until reinitiated by either a
transition of the local input or an update to nviOccManCmd.

This output network variable is available to report the Space

Comfort Controller status. It combines the operating mode, the
capacity of heating and cooling used and an indication if any
alarms are present in the object.

Sub

Name Valid

Value

01

mode

HVAC_AUTO

HVAC_HEAT

HVAC_MRNG_WRMUP

Not Used

HVAC_COOL

HVAC_NIGHT_PURGE

Not Used

HVAC_PRE_COOL

Not Used

HVAC_HVAC_OFF

HVAC_HVAC_TEST

Not Used

Unit Status
network
output

SNVT_hvac_status
nvoUnitStatus

HVAC_HVAC_EMERG_HEAT

– Not Used
