11

Standard Object Types Supported

Object Type

Supported

Objects

Dynamically

Creatable

Dynamically

Deletable

Optional

Properties

Supported

Writable

Properties

Analog Input

Reliability

Out_of_Service

Analog Value

Reliability

Present_Value

a,b

Out_of_Service

a

Object_Name

c

Binary Input

Reliability

Active_Text

Inactive_Text

Out_of_Service

Binary Value

Reliability

Active_Text

Inactive_Text

Present_Value

Out_of_Service

Device

Max_Master

Max_Info_frames

Object_Identifier

Object_name

Max_Master

Group

N/A

N/A

Multi-state Value

Reliability

States_Text

Present_Value

d

Out_of_Service

d


a : Present_Value and Out_of_Service properties are writable for every AV objects except :

 PI Heating Demand (AV21)
 PI Cooling Demand (AV22)

b : Present_Value property for Room Temperature (AV7) and Room Humidity (AV10) is writable only if

Room Temp Override (BV8) is enabled and Room Humidity Override (BV11) is enabled respectively.

c : Object_Name property is writable for the following object only :

 Room Temperature (AV7)

d : Present_Value and Out_of_Service properties are writable for every MV objects except :

 Output 2 (MV26)
 Output 1 (MV27)
 Fan Status (MV28)
 Effective Occupancy (MV33)

List of Proprietary Properties

Property name

ID

BACnet Data type

Description

Major_Version

1000

CharacterString

The version number of the BACnet
communications module. This is the hardware
version number

MS/TP_Address

1001

Unsigned

Display the MAC layer address of the module

MS/TP_Baud_Rate

1002

Unsigned

Display the communication baud rate of the
module

Sensor_Offset

1005

REAL

Display the temperature or humidity calibration
value. The range is

–5.0 deg F to 5.0 deg F for a

temperature and

–15% to 15% for humidity.
