6
No Sub
Point Name Type
VT7656B5
x00E
VT7605B5
x00E
VT7652B5
x00E
VT7600B5
x00E
VT7652A5
x00E
VT7600A5
x00E
VT7652H5
x00E
VT7600H5
x00E
22 nvoSccStatus UNVT_thermo_state_rtu
UNVT_thermo_state_hp X X X X X X X X
For all non heatpump models, associate with UNVT_thermo_state_rtu
1 fan_output True bit index 2 x x x x x x x x
2 cooling_stage_1 True bit index 3 x x x x x x x x
3 cooling_stage_2 True bit index 4 x x x x N/A N/A x x
4 auxiliary_contact True bit index 5 x x x x x x x x
5 heating_stage_1 True bit index 6 x x x x x x x x
6 heating_stage_2 True bit index 7 x x x x x x x x
7 service_alarm True bit index 12 x x x x x x x x
8 filter_alarm True bit index 13 x x x x x x x x
9 di2_direct_status True bit index 17 x x x x x x x x
10 di1_direct_status True bit index 18 x x x x x x x x
11 set_clock_alarm True bit index 22 x N/A x N/A x N/A x N/A
12 frost_protection_alarm True bit index 23 x x x x x x x x
13 local_pir_motion True bit index 24 x x x x x x x x
14 fan_lock_alarm True bit index 25
For all heatpump models, associate with UNVT_thermo_state_hp
1 fan_output True bit index 2 x x x x x x x x
2 compressor_stage_1 True bit index 3 x x x x x x x x
3 compressor_stage_2 True bit index 4 x x x x N/A N/A x x
4 auxiliary_contact True bit index 5 x x x x x x x x
5 heating_stage_1 True bit index 6 x x x x x x x x
6 reversing valve True bit index 7 x x x x x x x x
7 service_alarm True bit index 12 x x x x x x x x
8 filter_alarm True bit index 13 x x x x x x x x
9 di2_direct_status True bit index 17 x x x x x x x x
10 di1_direct_status True bit index 18 x x x x x x x x
11 set_clock_alarm True bit index 22 x N/A x N/A x N/A x N/A
12 frost_protection_alarm True bit index 23 x x x x x x x x
13 local_pir_motion True bit index 24 x x x x x x x x
14 fan_lock_alarm True bit index 25
23 nvoEffectSetpt SNVT_temp_p X X X X X X X X
24 nvoSetpoint SNVT_temp_p X X X X X X X X
25 nciSndHrtBt SNVT_time_sec X X X X X X X X
26 nciMinOutTm SNVT_time_sec X X X X X X X X
27 nciRcvHrtBt SNVT_time_sec X X X X X X X X
28 nciMajVer SCPT_maj_ver X X X X X X X X
29 nciMinVer SCPT_min_ver X X X X X X X X
30 nciLocation SNVT_str_asc X X X X X X X X
