4
SNVTs
1
and SCPTs
2
Table Per Model
No Sub
Point Name Type
VT7656B5
x00E
VT7605B5
x00E
VT7652B5
x00E
VT7600B5
x00E
VT7652A5
x00E
VT7600A5
x00E
VT7652H5
x00E
VT7600H5
x00E
0 nviSpaceTemp SNVT_temp_p X X X X X X X X
1 nviOutdoorTemp SNVT_temp_p X X X X X X X X
2 nviOccManCmd SNVT_occupancy X X X X X X X X
3 nviApplicMode SNVT_hvac_mode X X X X X X X X
4 nviSetpoint SNVT_temp_p X X X X X X X X
5 nviTimeSet SNVT_time_stamp X N/A X N/A X N/A X N/A
6 nciDaySched[0] UNVT_day_sched X N/A X N/A X N/A X N/A
7 nciDaySched[1] UNVT_day_sched X N/A X N/A X N/A X N/A
8 nciDaySched[2] UNVT_day_sched X N/A X N/A X N/A X N/A
9 nciDaySched[3] UNVT_day_sched X N/A X N/A X N/A X N/A
10 nciDaySched[4] UNVT_day_sched X N/A X N/A X N/A X N/A
11 nciDaySched[5] UNVT_day_sched X N/A X N/A X N/A X N/A
12 nciDaySched[6] UNVT_day_sched X N/A X N/A X N/A X N/A
13 nciSetPts SNVT_temp_setpt X X X X X X X X
1 occupied_cool x x x x x x x x
3 unoccupied_cool x x x x x x x x
4 occupied_heat x x x x x x x x
6 unoccupied_heat x x x x x x x x
14 nciCfg1RtuHp UNVT_cfg_1_rtu_hp X X X X X X X X
Associate with UNVT_cfg_1_rtu_hp format file
1 password Unsigned-Long x x x x x x x x
2 unoccupied_timer Unsigned-Short x x x x x x x x
3 anticycle Unsigned-Short x x x x x x x x
4 power_up_delay Unsigned-Short x x x x x x x x
5 temporary_occ_time Unsigned-Short x x x x x x x x
6 heating_stages_CPH Unsigned-Short x x x x x x x x
7 cooling_stages_CPH Unsigned-Short x x x x x x x x
8 heat_max_setpoint SNVT_temp_p x x x x x x x x
9 cool_min_setpoint SNVT_temp_p x x x x x x x x
10 OA_temp_heat_lockout SNVT_temp_p x x x x x x x x
11 OA_temp_cool_lockout SNVT_temp_p x x x x x x x x
12 calib_room_sensor SNVT_temp_diff_p x x x x x x x x
13 calib_outside_air_sensor SNVT_temp_diff_p x x x x x x x x
14 deadband Unsigned-Short x x x x x x x x
15 fan_mode Enumeration Set Used:
fan_mode_b-t x x x x x x x x
16 fan_control Enumeration Set Used:
off_on_state_t x x x x x x x x
17 fan_delay Enumeration Set Used:
off_on_state_t x x x x x x x x
18 keypad_lockout Enumeration Set Used:
rem_lock_t x x x x x x x x
19 proportional_band Unsigned-Short x x x x x x x x
20 temperature_units Enumeration Set Used:
temp_unit_t x x x x x x x x
21 frost_protection Enumeration Set Used:
off_on_state_t x x x x x x x x
22 menu_scroll Enumeration Set Used:
scroll_type_t x x x x x x x x
1: SNVTs: Standard Network Variables Types
2: SCPTs: Standard Configuration Parameters Types
