10
Parameter Variable Name Function
Supply
Temperature network output
SNVT_temp_p
nvoDischAirTemp This output network variable is used to monitor the temperature
of the air that leaves the Space Comfort Controller
Valid Range: -40 to 122°F (-40 to 50°C)
The value 621.81°F (327.67°C or 0x7FFF)will be sent as an
invalid value in case of a sensor failure.
This output network variable is used to indicate the actual
occupancy mode of the unit. This information is typically reported
to a supervisory controller or provided to another Space Comfort
Controller to coordinate the operation of multiple units
Valid Range:
0 = OC_OCCUPIED
1 = OC_UNOCCUPIED
2 = OC_BYPASS
1
Occupancy network output
SNVT_occupancy
nvoEffectOccup
3 = OC_STANDBY – Not Used
NOTE : OC_BYPASS can be initiated by either nviOccManCmd or a
local input. NvoEffectOccup will only be in OC_BYPASS for the
duration of the ToccTime (nciGenOpts), until reinitiated by either a
transition of the local input or an update to nviOccManCmd.
This network variable output is used to report the Space Comfort
Controller inputs’ and outputs’ status.
Sub Name Valid value True bit
index
fan output 0 = Off
1 = On 2
cooling stage 1
compressor stage 1 0 = Off
1 = On 3
cooling stage 2
compressor stage 2 0 = Off
1 = On 4
auxiliary contact 0 = Off
1 = On 5
heating stage 1 0 = Off
1 = On 6
heating stage 2
reversing valve
0 = Off
1 = On 7
service alarm 0 = Off
1 = On 12
filter alarm 0 = Off
1 = On 13
di2 direct status 0 = Activated
1 = Not Activated 17
di1 direct status 0 = Activated
1 = Not Activated 18
set clock alarm 0 = Off
1 = On 22
frost protection alarm 0 = Off
1 = On 23
local pir motion 0 = Off
1 = On 24
Thermostat’s
I/O status network output
UNVT_thermo_state_rtu
UNVT_thermo_state_hp
nvoSccStatus
fan lock alarm 0 = Off
1 = On 25
