Viconics VT7600 Echelon Integration Manual - Manual (Page 5)

5
No Sub
Point Name Type
VT7656B5
x00E
VT7605B5
x00E
VT7652B5
x00E
VT7600B5
x00E
VT7652A5
x00E
VT7600A5
x00E
VT7652H5
x00E
VT7600H5
x00E
15 nciCfg2RtuHp UNVT_cfg_2_rtu_hp X X X X N/A N/A X X
Associate with UNVT_cfg_2_rtu_hp format file
1 di1_config Enumeration Set Used:
input_cfg_model_d_t x x x x x x x x
2 di2_config Enumeration Set Used:
input_cfg_model_d_t x x x x x x x x
3 aux_contact_config Enumeration Set Used:
aux_contact_cfg_t
x x x x x x x x
4 number_of_events Enumeration Set Used:
nb_of_events_t x N/A x N/A x N/A x N/A
5 progresive_recovery Enumeration Set Used:
off_on_state_t x N/A x N/A x N/A x N/A
6 a.hp_rev_valve_config Enumeration Set Used:
rev_valve_b_t N/A N/A N/A N/A N/A N/A x x
7 a.number_of_heating_stages Enumeration Set Used:
nb_stages_t x x x x N/A N/A N/A N/A
8 number_of_cool_or_hp_stages Enumeration Set Used:
nb_stages_t x x x x N/A N/A x x
9 econo_min_position SNVT_lev_percent x x N/A N/A N/A N/A N/A N/A
10 b.hp_high_balance_point SNVT_temp_p N/A N/A N/A N/A N/A N/A x X
11 b.econo_changeover_setpoint SNVT_temp_p x x N/A N/A N/A N/A N/A N/A
12 c.hp_low_balance_point SNVT_temp_p N/A N/A N/A N/A N/A N/A x x
13 c.econo_mixed_air_setpoint SNVT_temp_p x x N/A N/A N/A N/A N/A N/A
14 d.hp_comfort_or_economy_mode Enumeration Set Used:
mode_t N/A N/A N/A N/A N/A N/A x x
15 d.econo mechanical_cool_enable Enumeration Set Used:
off_on_state_t x x N/A N/A N/A N/A N/A N/A
16 hp compressor_auxheat_interlock Enumeration Set Used:
off_on_state_t N/A N/A N/A N/A N/A N/A x x
16 nciHvacType SNVT_hvac_type X X X X X X X X
17 nciSccModel UNVT_model_numbe X X X X X X X X
1 Thermostat Model x x x x x x x x
2 Software Version x x x x x x x x
18 nvoSpaceTemp SNVT_temp_p X X X X X X X X
19 nvoUnitStatus SNVT_hvac_status X X X X X X X X
1 mode x x x x x x x x
2 heat_output_primary x x x x x x x x
3 heat_output_secondary N/A N/A N/A N/A N/A N/A x x
4 cool_output x x x x x x x x
5 econo_output x x N/A N/A N/A N/A N/A N/A
6 Fan_output x x x x x x x x
7 in_alarm x x x x x x x x
20 nvoDischAirTemp SNVT_temp_p X X X X X X X X
21 nvoEffectOccup SNVT_occupancy X X X X X X X X
