Operating Guide | TS-700 Series
A-11
Appendix For Scale Technicians
TS-700 SS
The 3-wire terminal block located on the main board
can be utilized to connect the indicator to a
peripheral device such as a printer or remote
display, or to interface the indicator with a PC.
NOTE: PC interface requires Triner DataLog PC™
software to be installed on the PC.
TS-700 SS RS-232 Terminal Block
TS-700 WB
The RS232 3-pin quick-connect serial port can be
utilized to connect the indicator to a peripheral
device such as a printer or remote display, or to
interface the indicator with a PC.
NOTE: PC interface requires Triner DataLog PC™
software to be installed on the PC.
