Triner Scale 600-E Series - Manual (Page 38)

Page C-2
# of External Full Scale Input Range (mV/V)
Grads 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
500 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25
1,000 50 25 25 25 25 25 25 25 25 25 25 25 25 25 25
1,500 75 50 25 25 25 25 25 25 25 25 25 25 25 25 25
2,000 100 50 50 25 25 25 25 25 25 25 25 25 25 25 25
2,500 150 75 50 50 25 25 25 25 25 25 25 25 25 25 25
3,000 150 75 50 50 50 25 25 25 25 25 25 25 25 25 25
4,000 200 100 75 50 50 50 50 25 25 25 25 25 25 25 25
5,000 – 150 100 75 50 50 50 50 50 25 25 25 25 25 25
6,000 – 150 100 75 75 50 50 50 50 50 25 25 25 25 25
8,000 – 200 150 100 75 75 75 50 50 50 50 50 50 50 25
10,000 – – 200 150 100 100 75 75 75 50 50 50 50 50 50
12,000 – – 200 150 150 100 100 75 75 75 50 50 50 50 50
15,000 – – – 200 150 150 100 100 100 75 75 75 75 50 50
20,000 – – – – 200 200 150 150 150 100 100 100 75 75 75
30,000 – – – – – – 200 200 200 150 150 150 150 100 100
40,000 – – – – – – – – – 200 – – 150 150 –
Table C-1: Minimum Recommended (6:1) Span Gain Table
