Page 25 – S5 Wireless Microphone Installation Guide Rev 1.5
Technical Specifications
Overall System
Frequency Bands available:
RF Switching BW: 36 MHz typ.
RF grid spacing: 25 kHz
RF Bandwidth: < 200 kHz
AF Frequency response: 60 Hz – 20 kHz
AF Distortion: < 0.8% at nom deviation 22 kHz
AF Dynamic range: >110 dBA
AF Noise reduction: Trantec proprietary
Temperature range: -10 °C to +55°C
Receiver Specification
Type: Dual Diversity featuring PLL Dual Double conversion receivers
IF Freq: 1
st IF 55.875 MHz; 2nd IF 10.7 MHz
Sensitivity: < 1 uV/12 dB SINAD
Ist Image: >70 dB
RSSI range: 10 steps 30 dB range
Antenna Inputs: BNC 50 Ω
AF switches: Low Cut – High Boost – Phase Reversal (S5.5 only)
AF Output level: XLR Line +15 dBm max; XLR Mic -25 dBm max; Unbalanced ¼”
jack socket +9 dBm max
Antenna Phantom: 9 V @ 60 mA short-circuit protected on each RF port
Bank Specification: 10 banks x 24 channels (S5.5) (6 banks Japanese version); 9
banks x 12 channels S5.3
Infra-Red Link: Range 15 cm max
Computer Interface: Computer monitoring via rear panel USB interface
Power Consumption: 300 mA @ 12 Vdc nominal
Beltpack Transmitter Specification
Power Supply: Single Alkaline “AA” cell 1.5 V nom.
Power consumption: typically 120 mA
Operating time: typically 8 - 10 hrs min.
Controls: On-Off, AF Gain Adjust, Frequency adjust
Gain Range: +2 dBm to -20 dBm in 10 steps
Dimensions: 55 mm x 80 mm x 20 mm
Weight 110 g
Due to our continual policy of research and development we reserve the right to alter
specifications without prior notice.
A1 692-722 MHz B1 722-752 MHz
B2 740-752 MHz C1 794-830 MHz
C2 794-806 MHz D1 863-865 MHz
D2 854-865 MHz (S5.3 only) D3 830-865 MHz
E1 668-698 MHz F1 636-668 MHz
G1 606-638 MHz (S5.5 only) G2 606-622 MHz (S5.3 only)
