Toa SR-EP3 - Manual (Page 8)

8
5.5. Line Array Speaker SR-H3S (Long and Curved type)
5.4. Line Array Speaker SR-H3L (Long and Linear type)
1
1
86.4 (46.71)
302
(11.89)
250
(9.84)
250
(9.84)
302
(11.89)
41.2
(1.62)
[Front] [Rear] [Side]
84 (3.31) 115 (4.53) 40 (1.57)
[Top]
Unit: mm (inches)
Input terminal
Blank panel
(The optional MT-S0301 Matching
Transformer can be installed inside.)
Bass reflex duct
(located on the top surface only)
Mounting screw (M5)
20°
264
(10.39)
250
(9.84)
250
(9.84)
254 (10)
41.2
(1.62)
1177.2 (46.35)
[Front] [Rear] [Side]
84 (3.31) 157 (6.18) 40 (1.57)
[Top]
Unit: mm (inches)
Input terminal
Blank panel
(The optional MT-S0301 Matching
Transformer can be installed inside.)
Bass reflex duct
Mounting screw (M5)
