CenterLine Real-Time Operation
CenterLine Real-Time Operation
Starting Real-time Operation
This section assumes that the setup section (See “CenterLine Setup” on page 13) has been read
and the CenterLine lightbar properly set up.
Start real-time operation by pressing Enter when is displayed in the text window. The
menu item is at the highest menu level. can be easily reached from most
menu levels by scrolling to and pressing Enter. This jumps to the location
from anywhere in the menu structure (See Figure 32).
Figure 34 is a flow diagram of the CenterLine real-time operation and menu.
New? Resume?
When Enter has been pressed at the location, a prompt to start a new field or resume
working in the current field appears. During real-time operation, CenterLine stores the vehicle’s
trajectory data. This allows the operator to stop working in a field before finished and return at a
later time, continuing where they left off. Only the current field is stored.
Use Up or Down to scroll between the and menu items. Selecting
clears the current field trajectory data and starts a new field in memory. Selecting
retains the current field trajectory data and allows the start of guidance using the
existing data.
Figure 34: Real-Time Operation Flow Diagram
STRAIGHT HEADLAND CURVED PATTERN
Real-time Menu
NEW AB MARK A MARK B
NEW?
RESUME?
SETUP
TOOLS
START
RIGHT
LEFT
CLOSE
AREA
APPLY OFF? APPLY ON?
EXIT
E-DIF WAIT
