16 CenterLine
CenterLine Setup
CenterLine
Software Version 1.10
Antenna
The Antenna sub-menu defines the spatial relationship between the GPS antenna and the vehicle
implement or delivery point. The GPS antenna should always be mounted along the vehicle center
line (See Figure 17). The two Antenna menu settings are Direction and Distance.
To enter the Antenna sub-menu, go to , scroll until is displayed in the
text window, and press Enter. As mentioned, there are two settings under Antenna: TION> or . The text window should display . Use Up or
Down to move between the and settings. Press Enter
when the desired setting is in the text window.
Direction
The Direction setting is the direction from the GPS antenna to the swath or delivery point (See Fig-
ure 17).
To change the Direction setting, go to the Antenna sub-menu of Guidance setup, scroll until
is displayed in the text window, and press Enter. Using Up or Down scroll through
the direction pick list (See Figure 15) until the desired direction is displayed in the text window.
Press Enter to save the setting and return to the Guidance setup menu.
Figure 14: Accessing the Antenna Sub-Menu
Figure 15: Setting the Direction to Swath
Setting Description
Back The swath or delivery point is behind the GPS receiver on
the vehicle along the vehicle center line.
Forward The swath or delivery point is in front of the GPS receiver on
the vehicle along the vehicle center line.
Table 2: Direction to Swath Settings
DIRECTION BEHIND
FORWARD
