Page 26: Spacing
22
CenterLine
CenterLine Setup
CenterLine
Software Version 1.10
Lightbar Setup
Lightbar setup allows the selection of several parameters related to the lightbar. There are five
lightbar settings: Drive Sensitivity
sages:
Spacing
The Spacing setting allows the selection of the distance that a single light on the lightbar LEDs rep-
resents.
To change the Spacing setting, go to Lightbar setup, scroll until
text window, and press Enter. To increase the spacing distance press UP; to decrease the spacing
press Down. Press the Enter key when the desired spacing is set. The Spacing range is 0.5 ft. to
9.5 ft., in 0.5’ increments.
Figure 23: The Lightbar Setup Flow
Setting Name
Default Value
Change at 1st
Time Start up
Spacing
1.5 ft.
Optional
Mode
Swath
Optional
Text 1
X-Track Error
Optional
Text 2
Applied Area
Optional
Steer bar?
No
Optional
Table 7: Lightbar Menu Item Default Settings
