Centerline product kits, Centerline kit without dgps receiver, Figure 6: centerline without dgps receiver – TeeJet CenterLine v1.10 User Manual
Page 13: Centerline, Centerline 9 centerline product kits, Centerline wireless remote
CenterLine
Software Version 1.10
CenterLine 9
CenterLine Product Kits
CenterLine Product Kits
CenterLine Kit without DGPS Receiver
Figure 6: CenterLine without DGPS Receiver
Bat
CenterLine
Power Cable
12'
5 Amp
Power Cable
12'
Acc
Boom Sense -
+12V when booms are ON
Ignition Sense -
+12V when ignition is ON
To
Battery
S
ens
e
CenterLine
Wireless Remote
CenterLine
CenterLine Lightbar
A GPS data cable is
required but not provided in kit.
UP
DOWN
MEN
U
ESC
BRIGHT
DIM
CenterLine
CenterLine
CenterLine
