Table 8B — Electrical Data — 48AJ,AK,AW,AY Units with Convenience Outlet (cont)
See Legend and Notes on page 28.
UNIT
SIZE
48A
VOLTAGE
3 PH, 60 Hz
VOLTAGE
RANGE
COMPRESSOR CONDENSER
FAN MOTOR
EVAPORATOR
FAN MOTOR
POWER
EXHAUST
CONVENIENCE
OUTLET
POWER SUPPLY
Cir A, No. 1 Cir A, No. 2 Cir B, No. 1 Cir B, No. 2
Min Max RLA LRA RLA LRA RLA LRA RLA LRA Qty FLA Hp FLA FLA (total) FLA MCA
Fuse or
HACR Brkr*
040
208 187 229 25.6 190 25.6 190 34.3 265 34.3 265 2
6.5
(ea)
15 46.2
— 7.0 210.6 250
23.6 7.0 234.2 250
20 59.4
— 7.0 227.1 250
23.6 7.0 250.7 300
25 74.8
— 7.0 246.3 300
23.6 7.0 269.9 300
230 207 253 25.6 190 25.6 190 34.3 265 34.3 265 2
6.6
(ea)
15 42.0
— 7.0 205.7 225
23.6 7.0 229.3 250
20 54.0
— 7.0 220.7 250
23.6 7.0 244.3 250
25 68.0
— 7.0 238.2 300
23.6 7.0 261.8 300
460 414 508 13.5 95 13.5 95 16.0 120 16.0 120 2
3.3
(ea)
15 21.0
— 3.5 102.0 110
12.6 3.5 114.6 125
20 27.0
— 3.5 109.5 125
12.6 3.5 122.1 125
25 34.0
— 3.5 118.2 150
12.6 3.5 130.8 150
575 518 632 10.2 75 10.2 75 12.9 80 12.9 80 2
2.6
(ea)
15 17.0
— 2.5 80.4 90
9.6 2.5 90.0 100
20 22.0
— 2.5 86.6 100
9.6 2.5 96.2 110
25 27.0
— 2.5 92.9 110
9.6 2.5 102.5 125
041
208 187 229 25.6 190 25.6 190 34.3 265 34.3 265 4
6.5
(ea)
15 46.2
— 7.0 210.6 250
23.6 7.0 234.2 250
20 59.4
— 7.0 227.1 250
23.6 7.0 250.7 300
25 74.8
— 7.0 246.3 300
23.6 7.0 269.9 300
230 207 253 25.6 190 25.6 190 34.3 265 34.3 265 4
6.6
(ea)
15 42.0
— 7.0 205.7 225
23.6 7.0 229.3 250
20 54.0
— 7.0 220.7 250
23.6 7.0 244.3 250
25 68.0
— 7.0 238.2 300
23.6 7.0 261.8 300
460 414 508 13.5 95 13.5 95 16 120 16 120 4
3.3
(ea)
15 21.0
— 3.5 102.0 110
12.6 3.5 114.6 125
20 27.0
— 3.5 109.5 125
12.6 3.5 122.1 125
25 34.0
— 3.5 118.2 150
12.6 3.5 130.8 150
575 518 632 10.2 75 10.2 75 12.9 80 12.9 80 4
2.6
(ea)
15 17.0
— 2.5 80.4 90
9.6 2.5 90.0 100
20 22.0
— 2.5 86.6 100
9.6 2.5 96.2 110
25 27.0
— 2.5 92.9 110
9.6 2.5 102.5 125
050
208 187 229 34.3 265 34.3 265 34.3 265 47 380 4
6.5
(ea)
20 59.0
— 7.0 257.2 300
23.6 7.0 280.8 300
25 75.0
— 7.0 276.4 350
23.6 7.0 300.0 350
30 88.0
— 7.0 292.9 350
23.6 7.0 316.5 400
230 207 253 34.3 265 34.3 265 34.3 265 47 380 4
6.6
(ea)
20 54.0
— 7.0 250.8 300
23.6 7.0 274.4 300
25 68.0
— 7.0 268.3 300
23.6 7.0 291.9 350
30 80.0
— 7.0 283.3 350
23.6 7.0 306.9 350
460 414 508 16 120 16 120 16 120 22.4 175 4
3.3
(ea)
20 27.0
— 3.5 120.9 125
12.6 3.5 133.5 150
25 34.0
— 3.5 129.6 150
12.6 3.5 142.2 175
30 40.0
— 3.5 137.1 175
12.6 3.5 149.7 175
575 518 632 12.9 80 12.9 80 12.9 80 18.6 140 4
2.6
(ea)
20 22.0
— 2.5 97.7 110
9.6 2.5 107.3 125
25 27.0
— 2.5 104.0 125
9.6 2.5 113.6 125
30 32.0
— 2.5 110.2 125
9.6 2.5 119.8 150
