Table 2 — Unit Operating Weights
Table 3 — Option and Accessory Weights
Table 4 — Constant Volume Fan Motor Weights
LEGEND
Table 5 — Variable Volume Fan Motor Weights
NOTES:
1. Base unit weight includes outdoor-air hoods. Base unit weight
does NOT include indoor-fan motor. ADD indoor-fan motor,
FIOPs, and accessories for TOTAL operating weight.
2. The VAV motor weights include indoor fan motor and the VFD
(variable frequency drive), VFD transducers, and associated
wiring.
UNIT
BASE UNIT WEIGHTS — lb
020 025 027 030 035 036 040 041 050 051 060
48AJ/AK Low Heat 3842 3915 4032 4182 4435 4815 4975 5091 5446 7224 7388
48AJ/AK High Heat 3922 3995 4112 4262 4595 4975 5135 5251 5606 7464 7628
48AW/AY Low Heat 3882 3955 4072 4222 4475 4855 5015 5131 5486 7264 7428
48AW/AY High Heat 3962 4035 4152 4302 4635 5015 5175 5291 5646 7514 7678
OPTION/
ACCESSORY
OPTION/ACCESSORY WEIGHTS — lb
020 025 027 030 035 036 040 041 050 051 060
Barometric Relief 300 300 300 300 300 300 300 300 300 450 450
Power Exhaust 450 450 450 450 450 450 450 450 450 675 675
Mod. Power Exhaust 500 500 500 500 500 500 500 500 500 725 725
Cu Tubing/Cu Fin Condenser Coil 220 220 220 220 285 380 285 380 380 651 651
Outdoor Air Hood Crate and Packaging
(Less Hoods' Weight) 45 45 45 45 45 45 45 45 45 45 45
(Packaging Only) (Packaging Only)
Outdoor Air Hoods/Filters 170 170 170 170 170 170 170 170 170 255 255
Hail Guard 73 73 73 73 73 146 146 146 146 219 219
Roof Curb (14-in.) 365 365 365 365 410 410 410 410 410 540 585
CV MOTOR WEIGHTS — lb
MOTOR
HP
UNIT
VOLTAGE
HIGH
EFFICIENCY
IFM
PREMIUM
EFFICIENCY
IFM
5
230/460 78 94
575 78 92
10
230/460 118 164
575 118 156
15
230/460 150 217
575 150 220
20
230/460 212 250
575 212 258
25
230/460 240 309
575 240 319
30
230/460 283 355
575 283 359
40
230/460 372 415
575 372 410
Cu — Copper
CV — Constant Volume
FIOP — Factory-Installed Option
HP — Horsepower
IFM — Indoor Fan Motor
VAV — Variable Air Volume
VFD — Variable Frequency Drive
VAV MOTOR WEIGHTS — lb
MOTOR
HP
UNIT
VOLTAGE
HIGH
EFFICIENCY
IFM
PREMIUM
EFFICIENCY
IFM
5
230/460 125 141
575 163 177
10
230/460 204 250
575 204 242
15
230/460 238 305
575 240 310
20
230/460 348 386
575 304 350
25
230/460 377 446
575 375 454
30
230/460 480 552
575 418 494
40
230/460 637 680
575 587 625
LEGEND AND NOTES FOR TABLES 2-5
