26
LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use &
Care section). Once cylinder has been filled and leak checked, place cylinder into hole in bottom shelf. Make sure cylinder
valve is facing front of grill. Secure cylinder with cylinder screw under bottom shelf. Insert regulator through large hole in
right side panel. See Use & Care section of this manual to perform the “Burner Flame Check” and for
important safety instructions before using.
Always keep LP cylinders in upright position during use,
transport, and storage.
Cylinder screw at rear of cart
Regulator
CAUTION
Cylinder valve must face to front of cart once
tank is attached. Failure to install cylinder
correctly may allow gas hose to be damaged
in operation, resulting in the risk of fire.
