Char-Broil RED 463250811 User Manual
Page 28
23
Slide one drawer along lower tracks into cart left. Slide the other drawer along upper tracks into the cart.
28
Drawer
22
Drawer
Drawer front panel
Attach drawer front panel to drawer using four #10-24x3/8” screws, 5mm lock washers and 5mm flat washers.
#10-24x3/8” Screw
5mm Lock Washer
5mm Flat Washer
Repeat for second drawer.
