Char-Broil RED 463250811 User Manual
Page 25
17
A
25
1/4-20x1½”
1/4-20x3/4” screw
1/4” nut
Attach front of shelf using two #8x3/8” self-tapping screws and large flat washers, shown B.
Attach rear of shelf using one 1/4-20x1½” screw, shown C.
Attach left side shelf using two 1/4-20x3/4” screws and 1/4” nuts, shown A. .
#8x3/8” self-tapping
Large flat washer
screw
screw
B
C
