Char-Broil RED 463250811 User Manual
Page 18
6
7
Attach drawer upper panel to drawer right panel using three #8x3/8” self-tapping screws. Attach drawer upper panel to cart
left side panel using two #8x3/8” self-tapping screws.
18
Drawer upper panel
Cart left side panel
#8x3/8”
self-tapping screw
#8x3/8”
self-tapping screw
1/4-20x1/2”
screw
Upper back panel
Lower back panel
Inside of cart, attach middle of upper back panel to lower back panel using one 1/4-20x1/2” screw.
Drawer right panel
