Char-Broil RED 463250811 - Manual (Page 24)

16
24
A
C
D
Left side fascia
Left side shelf
Left side shelf
Left side shelf
Side burner lid
Attach left side fascia to left side shelf using four
Attach side burner lid handle to side burner lid using two #10-24x3/8” screws, 5mm lock washers and 5mm flat washers,
shown B.
#10-24x3/8” screws, 5mm lock washers and 5mm flat washers, shown A.
Insert flange on left side shelf into side shelf brackets on side of firebox, shown D.
#10-24x3/8”
screw
5mm Lock
5mm Flat
Hinge
washer 5mm Lock
washer
washer
5mm Flat
washer
B
Place side burner lid onto left side shelf and align hinge holes in back of lid with shelf holes. Secure lid to the shelf using four
#8-32x3/8” screws, 4mm flat washers, 4mm lock washers, and #8-32 hex nuts, shown C.
#8-32x3/8” screw
#8-32 hex nut
4mm lock
washer
4mm flat
washer
side shelf bracket
#10-24x3/8”
Side burner lid
Side burner lid
handle
screw
