Chapter 3. Hardware Description

3.4.2 Pin Specifications

Pin Specification and its usages are as follows.

◆

Power JACK

LED

Power Jack

DB9

RJ-45

Reset Switch

Contact

Polarity

Center

+5VDC ± 5%(400mA or above)

Outer Ground

3-16
