ECUsim™ 5100 User Guide
8.0 Firmware Updates
Each PIM features a bootloader, which allows the user to update the device’s
firmware in the field through the USB port. Updates are posted on the ECUsim
internet product page as they become available.
Once you download the update, follow the steps to update the PIM:
1. Extract the contents of the ZIP file to a folder on your computer.
2. Run StnFirmwareUpdater.exe.
3. Set the PIM Select switch to the PIM that you wish to update. Be sure
the PIM ALL switch is in the “up” (off) position.
4. Select the COM port associated with the ECUsim.
5. Click the Upload Firmware button to program the PIM with the new
firmware.
To update additional PIMs, repeat steps 3 and 4.
ECUsim Product Page
