16 ECUsim™ 5100 User Guide
7.1.2 ECM: Mode 2
When the user generates a malfunction event, the following freeze frame is
stored:
PID Description Hex Value Scan Tool
Display
00 Supported PIDs 01-1F 48180000
02 DTC that Caused F.F. Storage 0100 P0100
05 Engine Coolant Temperature 8C 100°C
0C Engine RPM 4E20 5000 rpm
0D Vehicle Speed Sensor 78 120 km/h
7.1.3 ECM: Mode 3
When the MIL is on, Mode 3 reports six DTCs:
 P0100
 P0200
 P0300
 C0300
 B0200
 U0100
7.1.4 ECM: Mode 4
Issuing Mode 4 request performs the following operations:
 Turn off MIL (Mode 1, PID 1)
 Erase Freeze Frame (Mode 2)
 Erase stored DTCs (Mode 3)
 Erase pending DTCs (Mode 7)
