ECUsim™ 5100 User Guide 19
7.2.4 TCM: Mode 7
When MIL is on, Mode 7 reports two DTCs:
 P0102
 U1600
7.3 ABS Control Module (ABS)
The following summarizes modes, PIDs, and Infotypes supported by the ABS.
7.3.1 ABS: Mode 1
PID Description Fixed/Variable Hex Value Scan Tool
Display
00 Supported
PIDs 01-1F fixed 00080010
0D Vehicle Speed
Sensor variable, knob #3 00 to FF 0 to 255 km/h
1C OBD Type fixed 01 OBD-II (CARB)
7.3.2 ABS: Mode 4
Issuing Mode 4 request performs the following operations on the ABS:
 Erase pending DTCs (Mode 7)
7.3.3 ABS: Mode 7
When MIL is on, Mode 7 reports one DTC:
 B2245
