ECUsim™ 5100 User Guide 17
7.1.5 ECM: Mode 7
When the MIL is on, Mode 7 reports four pending DTCs:
 P0107
 P0207
 P0307
 C0307
7.1.6 ECM: Mode 9
The following infotypes are supported:
Infotype Description Scan Tool Display
00 Supported Infotypes
01 VIN Message Count
*
02 VIN 1G1JC5444R7252367
03 Calibration ID message count
*
04 Calibration ID JMB*36761500
05 CVN Message Count
*
06 CVN 1791BC82
0A ECUNAME ECU1-EngineControl
* Message count infotypes are not supported in ISO 15765-4, per SAE J1979.
7.1.7 ECM: Mode A
After the first MIL event (user pressed the “MIL” button), Mode A reports one
permanent DTC:
 P1234
This mode is only available for ISO15765-4.
SAE J1979 does not define Mode A for the SAE J1850, ISO 9141-2,
or ISO 14230-4 protocols.
Permanent DTCs cannot be erased using a Mode 04 request.
To erase this DTC, you must reset the PIM by issuing the RESET
command, momentarily deselecting it using the PIM Select switch,
or power cycling the simulator.
