14 ECUsim™ 5100 User Guide
7.1 Engine Control Module (ECM)
The following summarizes modes, PIDs, and Infotypes supported by the PCM.
7.1.1 ECM: Mode 1
PID Description Fixed/Variable Hex Value Scan Tool
Display
00 Supported PIDs
01-1F fixed BE1B3013
01 Monitors/DTC
Count/MIL fixed
1
0007EF80 See PID 01
Monitors table
03 Fuel System
Status fixed 0201 Closed Loop/
Open Loop
04 Calculated Load
Value fixed 32 20%
05 Engine Coolant
Temperature variable, knob #1 00 to FF -40°C to +215°C
06 Short Term Fuel
Trim: Bank 1 fixed 3C -53.1%
07 Long Term Fuel
Trim: Bank 1 fixed 46 -45.3%
0C Engine RPM variable, knob #2 0000 to
FFFF 0.00 to
16383.75 rpm
0D Vehicle Speed
Sensor variable, knob #3 00 to FF 0 to 255 km/h
0F Intake Air
Temperature fixed 41 25°C
10 Mass Air Flow variable, knob #4 0000 to
FFFF 0.00 to
655.35 g/s
13 Location of
Oxygen Sensors fixed 01 Bank 1, Sensor 1
14 Oxygen Sensor
Voltage variable, knob #5 00 to FF 0.000 to 1.275 V
14 Short Term Fuel
Trim fixed 80 0%
1C OBD Type fixed 01 OBD II (CARB)
1 When FAULT button is pressed, the MIL bit and DTC count bits change.
