ECUsim™ 5100 User Guide 13
7.0 Virtual ECUs
There are three virtual ECUs: Engine Control Module (ECM), Transmission
Control Module (TCM), and Anti-lock Braking System module (ABS). The ECUs
support both physical and functional addressing, as specified in the SAE
J2178, Part 1 and ISO 15765-4 documents.
Functional address supported by the ECUs depend on the selected protocol
and, in the case of ISO 15765-4, the ID type (11-bit or 29-bit):
Protocol(s) Functional
Address
J1850 PWM
J1850 VPW
ISO 9141-2 $6A
ISO 14230-4
ISO 15765-4 (29-bit) $33
ISO 15765-4 (11-bit) $7DF
Physical address assignments also depend on the protocol and CAN ID in use,
and are summarized in the following table:
ECU ISO 15765-4
(11-bit ID)
Other
Protocols
Engine Control Module (ECM) $7E0 $10
Transmission Control Module (TCM) $7E1 $18
ABS Module (ABS) $7E2 $28
29-bit ISO 15765-4, SAE J1850, ISO 9141-2, and ISO 14230-4 addresses follow
the physical address assignments outlined in SAE J2178, Part 1.
