ScanTool Ready-or-Not - Manual

1. Install OBDwiz software 2. Locate the diagnostic connector.
Insert the software CD in your CD-ROM drive.
The scan tool selection menu will automatically
appear. Click on the icon labeled Ready-or-Not:
5. Launch OBDwiz software
To launch the software, click on Start
Programs
. Click the Auto
Detect button, then click the Connect button.
6. Technical support
Should you run into problems, technical support
is just a click away:
3. Connect Ready-or-Not (RoN) to
the DLC
Follow connection diagram (directly below) to
connect RoN to the diagnostic connector using
The Ready-or-Not menu will appear. Click on
the black OBD-II cable (steps & ). OBDwiz and follow the prompts to install the
software:
4. Connect scan tool to the PC
Connect RoN to your PC's serial port using the
gray serial cable (steps & ). Turn the vehicle’s
ignition to the Key On, Engine Off position.
Note that some laptops do not have a built-in
serial port. Inexpensive USB to Serial converters
are available from the ScanTool.net website, or
your local computer store.
º If the menu does not appear, click Start Run,
type D:\setup.exe (where ‘D’ is the drive letter of
your CD-ROM drive), and click OK.
Watch the LEDs as you are performing step .
The six monitor LED’s will momentary light up
green then red, followed by a “beep” sound.
The 16-pin D-shaped diagnostic link connector
g
(DLC) should be located in the passenger or
gOBDwizgOBDwiz
driver's compartment in the area bounded by the
driver's end of the instrument panel to 300 mm
(~1 ft) beyond the vehicle centerline, attached to
the instrument panel and easy to access from the
driver's seat. The preferred location is between
the steering column and the vehicle centerline.
— Knowledgebase - contains answers to
the most commonly asked questions,
general information about OBD-II, and
troubleshooting information.
— Forum - allows you to share information
and get support from other ElmScan 5
users.
All of the above resources can be accessed from
our website:
A B
B
C D
www.ScanTool.net .
TM
A
vehicle OBD-II cable serial cable
B C D
Ready-or-Not Ready-or-Not Ready-or-Not Ready-or-Not Ready-or-Not Ready -or- Not TM
CA
T
EV
AP
SEC.
AIR
O 2 O
HTR 2 EGR
READY NOT READY
RoN
computer
