18 ECUsim™ 5100 User Guide
7.2 Transmission Control Module (TCM)
The following summarizes modes, PIDs, and Infotypes supported by the TCM.
7.2.1 TCM: Mode 1
PID Description Fixed/Variable Hex Value Scan Tool
Display
00 Supported PIDs
01-1F fixed 88180010
01 Monitors/DTC
Count/MIL fixed
*
00000000 All monitors not
supported
05 Engine Coolant
Temperature variable, knob #1 00 to FF -40°C to +215°C
0C Engine RPM variable, knob #2 0000 to
FFFF 0.00 to
16383.75 rpm
0D Vehicle Speed
Sensor variable, knob #3 00 to FF 0 to 255 km/h
1C OBD Type fixed 01 OBD-II (CARB)
* When the FAULT button is pressed, the MIL bit gets set, and the DTC count bits change to reflect
the number of stored DTCs.
7.2.2 TCM: Mode 3
When MIL is on, Mode 3 reports one DTC:
 P0101
7.2.3 TCM: Mode 4
Issuing Mode 4 request performs the following operations on the TCM:
 Erase stored DTCs (Mode 3)
 Erase pending DTCs (Mode 7)
