Form P-UEAS, P/N 269865R4, Page 2
Serial No. Date of
Manufacture
Sample of Model UEAS
Rating Plate
Rating Plate Key:
B = Model No.
C = Date of Manufacture
(Month & Year)
D = Volts; Phase; Hertz;
Input Amps
E = Fuel Type (natural gas
or propane)
F = Orifice Size
G = Normal Manifold Pres-
sure (inches w.c.)
H = Minimum Gas Supply
Pressure (inches w.c.)
J = Normal BTUH Input (sea
level)
L = Thermal Output BTUH
(sea level)
M = Minimum BTUH Input
(sea level)
Year Jan Feb Mar Apr May June July Aug Sept Oct Nov Dec
2007 BGA BGB BGC BGD BGE BGF BGG BGH BGI BGJ BGK BGL
2008 BHA BHB BHC BHD BHE BHF BHG BHH BHI BHJ BHK BHL
2009 BIA BIB BIC BID BIE BIF BIG BIH BII BIJ BIK BIL
2010 BJA BJB BJC BJD BJE BJF BJG BJH BJI BJJ BJK BJL
2011 BKA BKB BKC BKD BKE BKF BKG BKH BKI BKJ BKK BKL
2012 BLA BLB BLC BLD BLE BLF BLG BLH BLI BLJ BLK BLL
2013 BMA BMB BMC BMD BME BMF BMG BMH BMI BMJ BMK BML
2014 BNA BNB BNC BND BNE BNF BNG BNH BNI BNJ BNK BNL
2015 BOA BOB BOC BOD BOE BOF BOG BOH BOI BOJ BOK BOL
2016 BPA BPB BPC BPD BPE BPF BPG BPH BPI BPJ BPK BPL
2017 BQA BQB BQC BQD BQE BQF BQG BQH BQI BQJ BQK BQL
2018 BRA BRB BRC BRD BRE BRF BRG BRH BRI BRJ BRK BRL
2019 BSA BSB BSC BSD BSE BSF BSG BSH BSI BSJ BSK BSL
2020 BTA BTB BTC BTD BTE BTF BTG BTH BTI BTJ BTK BTL
Rating Plate and
Serial No.
Serial No. Decoding
Serial No. Sample: BLK 79 6E N 00000
Elements of No.: 1 | 2 | 3 |4| 5
Prefix to Serial No. Prefix Key: E = E3 (409) Stainless Steel Heat Exchanger
Key: 1 = Date of Manufacture Code
(See table below.)
2 = Ignition Code (See Form P-Valves.)
3 = Valve Code (See Form P-Valves.)
4 = Type of Gas (N = Natural;
L = Propane)
5 = Consecutive number
REZNOR
MERCER, PA. USA 16137
MADE IN MEXICO
SEPARATED COMBUSTION SYSTEM UNIT HEATER
CATEGORY IV
ANSI Z83.8 CSA 2.6
UNIT HEATER
MODEL [ B ] [ C ]
SERIAL NO.
[
D ] VOLTS [ D ] PH [ D ] HZ MAXIMUM TOTAL INPUT [ D ] AMPS
TYPE OF GAS: [ E ]
FOR USE AT 0-2000 FEET, 0-610 METERS OF ALTITUDE.
ORIFICE SIZE [
F ] DRILL
SEA LEVEL
NORMAL INPUT [ J ] BTU/HR
THERMAL OUTPUT CAPACITY [ L ] BTU/HR
MINIMUM INPUT [ M ] BTU/HR
NORMAL MANIFOLD PRESSURE [ G ] IN.W.C.
MIN. PERMISSIBLE GAS SUPPLY PRESSURE
FOR PURPOSE OF INPUT ADJUSTMENT. [
H ] IN.W.C.
CLEARANCES TO COMBUSTIBLE CONSTRUCTION: TOP-4", FLUE
CONNECTION-0", CONTROL SIDE-18", OPP. SIDE-2", BOTTOM-1", FRONT-36"
FOR ALTERNATE INSTALLATIONS USE THE LATEST EDITIONS OF THE
APPROPRIATE STANDARD LISTED BELOW:
FOR AIRCRAFT HANGARS USE STANDARD ANSI/NFPA 409
FOR PARKING STRUCTURES USE STANDARD ANSI/NFPA 88A
FOR REPAIR GARAGES
USE STANDARD ANSI/NFPA 88B
THIS UNIT IS NOT FOR USE WITH DUCTS.
THIS UNIT IS NOT FOR USE WITH FILTERS.
CONSTRUCTION WALL THICKNESS FOR PURPOSE OF VENTING:
1" MIN., 48" MAX.
In the event the vent temperature limit switch causes the heater to shut off.
Determine and correct the cause. Failure to do so could result in personal
injury or death. To reset, depress the button on the sensor located on the side
of the venter housing.
