26
Top View
Side View
back View
24 9/10
13 1/2
16
12
13 3/10
13 1/2
16
12
CG
A
47 1/2
3/4" NPT Female
Drain Connector
B
DOWNFLOW
SUPPLY DUCT
OPENING
DOWNFLOW
RETURN DUCT
OPENING
23 1/2
Table 9. Center of gravity & Unit Shipping Weights
47.5
Electric
Supply Entry
Low Voltage Entry
Gas Supply
Entry
15.75
23.75
29.75
2.9
1.8
4.0
12.45
12.45
4.0
D
8.75
Horizontal
Supply Duct
Opening
Horizontal
Return Duct
Opening
4.0 1.75
9.75 24.75
16.0
Condensing
Coil
13.5
16.0 16.0
C
13.5
FIgURES & TAbLES
Figure 11. Unit Dimensions
Model Number Unit Weight
Center of gravity Height (in inches)
C
D
A B
with base rails without base rails
X24K080CA 480 26.0 27.0 39.0 35.3 55.8
X36K100CA 599 27.0 26.5 39.0 35.3 55.8
X48K120CA 618 27.0 26.5 47.0 43.3 55.8
X60K120CA 655 30.0 26.5 47.0 43.3 63.6*
* Extended base pan models use same roof curb as 2 - 4 ton units.
