ADSL IP DSLAM
82
Example: This example shows how to configure the VPI-0, VCI-50, up
Administration status, enable VLAN tag with VLAN ID-4002 and highest
connection priority on port 8.
IPDSLAM # add connection 8 0/50 up b 4002 7
Port 8
PVC: 0/50
AdminStatus: up
VID: 4002
rfc1483 b
Priority: 7
yes or No
This example shows how to configure the VPI-0, VCI-50, up Administration
status, and without VLAN tag on port 8 of unit 1
IPDSLAM # add connection 8 0/50 up
Port 8
PVC: 0/50
AdminStatus: up
yes or No
Note:
(1) Virtual Connection can be configured up to 2 connections on the same port
but the VLAN ID can not overlap with the existing VLAN ID.
(2) The default setting for PVC is 8/81, and you can modify and delete the
default setting.
(3) The default setting of VLAN ID is without VLAN tag.
(4) On the same port, one PVC or two PVCs can be created. On the creation of
one PVC, the configuration of VLAN ID can either be enabling VLAN tag or
disabling VLAN tag. On the creation of two PVCs, the configuration of
VLAN ID can either be enabling both VLAN tags or just disabling VLAN tag
on a PVC whereas the other will remain with VLAN tag. The situation of
both PVC without VLAN tag cannot be configured. Please refer to the table
4-13 for understanding ways of PVC configuration either with VLAN tag or
without VLAN tag:
Table 4-14 Ways of PVC configuration either with VLAN tag or without VLAN tag
Port 1
st
PVC
2
nd
PVC
With VLAN tag
With VLAN tag
Without VLAN tag
The same
port
Without VLAN tag
With VLAN tag
