ADSL IP DSLAM
23
3.3 Default (Factory) Configuration Settings {Default
Setting}
This section describes how to get the information of the default setting of your
ADSL IP DSLAM.
1. Click on “Default Setting” from the ADSL IP DSLAM Main Menu.
The Default Setting screen appears as follows:
Default Settings
SNMP:
community : “public”
no In-band management channel
IP
IP : 192.168.100.111
Mask: 255.255.255.0
Gateway: 192.168.100.1
System
Bridge – mode
Port-Filter(Port-based VLAN) : Enable
ADSL Port
“up” for all ports
VCC
connection
8/81(vpi/vci) for all ports
VLAN – tag : disable
DSL profile
named “DEFAULT”
1) tx mode : “adaptAtStartup”
2) Line type : “Interleaved”
3) Target SNR margin : “6 dB”
4) mim tx rate : “32 Kbps”
5) max tx rate at ATU-C : “8064 Kbps”
6) max tx rate at ATU-R : “1024 Kbps”.
7) interleave delay : “16 milliseconds”
Alarm
profile
named “DEFAULT”
ATU-C side:
Thresh15MinLofs – 0 sec
Thresh15MinLoss – 0 sec
Thresh15MinLols – 0 sec
Thresh15MinLprs – 0 sec
Thresh15MinEss – 0 sec
initial failure trap – Enable
ATU-R side :
Thresh15MinLofs – 0 sec
Thresh15MinLoss – 0 sec
Thresh15MinLols – 0 sec
Thresh15MinLprs – 0 sec
In the default setting table, the status of SNMP, IP, System, ADSL Port, VCC
connection, DSL profile and Alarm profile are displayed clearly. How to modify
them will be introduced in the following sections.
