ADSL IP DSLAM
71
4.5 Configuring DSL
Creating Line Profile and Alarm Profile
Creating DSL Profile
Describes how to create a DSL Profile.
Command: add lineprof
Argument List:
Parameter type Parameter data-type and
field Description
lineprof name String, <= 32 The name of ADSL line
profile.
Rate Mode Integer,
fixed : (1)
adaptAtStartup : (2) Defines what form of
transmitting rate to be
adaptated.
Line Type Fast : (1)
Interleaved : (2) The ADSL line type.
TargetSnrMargin Integer, 2 ~ 15 Target Signal / Noise
Margin.
MinTxRate Integer,
ATU-C: “32~ 8064”
ATU-R: “32 ~ 1024”
The minimum transmitting
rate of ATU-C side or
ATU-R side.
MaxTxRate Integer,
ATU-C: “32 ~8064”
ATU-R: “32 ~1024”
The maximum
transmitting rate of ATU-C
side or ATU-R side.
MaxInterleaveDelay Integer, 1,2,4,8,16,32,64 The value of Interleave
Delay for this channel.
Note:
1. If you select “Line Type” as “Fast”, you cannot select the value of
“MaxInterleaveDelay”. Please refer to the first example.
2. If you select “Rate Mode” as “Fixed”, the configuration of “MinTxRate”
and “MaxTxRate” must be the same. Please refer to the second
example.
Example1: This example shows how to create a DSL profile named
service512K64K.
IPDSLAM # add lineprof service512K64K
(lineprof-atuc)# 2 2 7 32 512 8
(lineprof-atur)# 2 2 7 32 64 8
ADSL Line Profile “SERVICE512K64K” content:
ATU-C:
