ADSL IP DSLAM

72

Rate Mode: adaptAtStartup
LineType: Interleaved
TargetSnrMargin: 7
MinTxRate: 32
MaxTxRate: 512
MaxInterleaveDelay: 8
ATU-R:
Rate Mode: adaptAtStartup
RateChanRatio: Interleaved
TargetSnrMargin: 7
MinTxRate: 32
MaxTxRate: 64
MaxInterleaveDelay: 8
Yes or No

Example 2: This example shows how to create a DSL profile named fast.

IPDSLAM # add lineprof fast
(lineprof-atuc)# 1 1 6 768 768
(lineprof-atur)# 1 1 6 128 128
ADSL Line Profile “fast” content:
ATU-C:
Rate Mode: fixed
LineType: Fast
TargetSnrMargin: 6
MinTxRate: 768
MaxTxRate: 768
ATU-R:
Rate Mode: fixed mode
RateChanRatio: Fast
TargetSnrMargin: 6
MinTxRate: 128
MaxTxRate: 128
Yes or No

Note: The configuration of default DSL profile named “DEFAULT” is as follows:

ATU-C:

1. RateMode:

AdaptAtStartup

2. RateChanRatio:

Interleaved

3. TargetSnrMargin:

6.0

4. MinTxRate:

32

5. MaxTxRate:

8064

6. MaxInterleaveDelay:

16

ATU-R:

1. Rate

Mode:

adaptAtStartup

2. RateChanRatio:

Interleaved

3. TargetSnrMargin:

6.0

4. MinTxRate:

32
