6
PRODUCT DESCRIPTION
General
Shown with Optional Fowler (Back Rest)
Upholstered Top
Electric
Lift Towers (2)
Optional
electric
Fowler (1)
For electrical specs, see Specifications section.
hand control
optional foot control
Locking
Casters (4)
Paper roll
holder (1)
up
to
7
5º
Fo
wle
r ang
le
STANDARD SPECIFICATIONS
Motion 1 Powered 22”-38” (55.9-96.5 cm.) Height Range
Motion 2 Powered ±15º Trendelenburg/ Reverse
Trendelenburg
Motion 3 (option) Powered 0-75º Fowler
Hand Control 3 or 2 section General – Motions 1-3
1 section General – Motions 1 & 2
Paper Roll Holder Accommodates up to 21” (53.3 cm.) rolls
(roll not included)
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity
550 lbs. (250 kg.) (patient and accessories)
Widths 27” (69 cm.) or 30” (76 cm.)
Length - 1 section Rectangular Top – 72” (183 cm.)
Length - 2 section Fowler – 34” (86 cm.), Seat – 38” (97 cm.)
Length - 3 section Fowler – 34” (86 cm.), Seat – 24” (61 cm.),
Leg Rest – 13” (33 cm.)
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or
permanent positioning
Padding 3” (8 cm.) Comfort Foam
™
Upholstery Terra Touch ™
Table Weight * 359 lbs. (163 kg.)
Warranty 3 year parts, 1 year labor
Safety Listings FDA, cETLus, CE marked
OPTIONS
Electric Fowler
Manual 4 Position Leg Rest
Central Base Locking System
Sliding Cardio Panel - Electric or Manual (30” Width & Left
side only)
Side Rails (2)
Adjustable access/back support - Left (3, 2 &1 section
tables)
Adjustable access/back support - Right (3, 2 &1 section
tables)
Foot Control - All powered motions
Patient Lift Compatible Base
ACCESSORIES
Detachable Arm Board
T-rail Adapter
QuickLock Face Pad
Accessory Mounting Plate (Per end - Fowler end only on 3
section tables)
Table Extender - 12” (30.5 cm.) Long
