11
DIR
e
CTIONS
f
OR
US
e
DIReCTIONS fOR USe
optional accessory
available on salon top only
Manicure Arm Rests Adjustable Side Arm Rests
1. Insert end of arm rest into
hole in backrest while holding
arm rest at 60° angle.
2. Push end all the way into hole and drop arm rest into horizontal
position. Tug slightly to make sure the armrest is fully locked to
the table (for patient safety).
To remove the arm rest, simply reverse the procedure above.
to install the arm rest:
The arm rests adjust automatically as the table’s back support moves to remain parallel to the floor in any position.
They are designed to be strong and will take a reasonable amount of weight, but they are not designed to be used to
sustain a person’s weight when getting on or off the table.
Caution: Do not use the arm rest
for customer weight support during the
mounting or dismounting of the table.
the arm rest is not designed to support
the patient’s weight.
The arm rest height is adjusted to level at the factory. When in use, some of the new
parts will wear, and you may see some sagging of the arm rest over time. If the arm
rest is too low the height can easily be adjusted using the enclosed Allen wrench.
1. Loosen bottom 2 set screws
(turn counter-clockwise).
2. Turn side set screw in (clock-
wise) while lightly raising the arm
rest with your other hand (to make
the adjustment easier).
3. When you have achieved the desired
height, tighten the two bottom set screws
(turn clockwise).
1. Loosen bottom 2 set screws
(turn counter-clockwise).
2. Turn side set screw out (turn
counter-clockwise).
3. When you have achieved the desired
height, tighten the two bottom set screws
(turn clockwise).
To Raise the Arm Rest
To Lower the Arm Rest
to level the arm rest:
arm rest installation and adjustment instructions
