Editing parameters – Novak Pit Wizard User Manual
Page 20
20
PIT WIZARD INSTRUCTION MANUAL
9. The Toggle Options are two position switches that turn on and
off features in the Cyclone speed control. One (1) indicates
that the features is turned on, and a zero (0) is off.
To modify the Toggle Options (2A):
•Press the {ENTER} button at the Toggle Options sub-screen:
2A Toggle Opt.
•Eight toggles that can be switched will be displayed:
Toggle Select
00000000
•Press the {UP} or {DOWN} buttons to move left or right and
select which toggle to switch (The toggle with a line under it).
•Press the {ENTER} button to change the selected toggle.
Note: Currently, only the first toggle from the left controls a feature
in the Cyclone. This toggle will allow the Drag Brake Value to be
adjusted with the Brake pot on the speed control.
The second toggle from the left indicates whether or not the
throttle channel on your tranmitter is reversed. If this toggle
displays a “1” (rev.), a “#” symbol will also be displayed to the
left of the value on the Full Throttle and Full Brake sub-screens.
For Drag Brake ON the display should read:
Toggle Select
10000000
•Press the {MODE} to make Toggle changes and exit back out
to the Toggle Options sub-screen:
2A Toggle Opt.
10. Press {MODE} button again to exit back out to the main menu.
EDITING PARAMETERS
(CONT.)
