Page 18
18
PIT WIZARD INSTRUCTION MANUAL
EDITING PARAMETERS
This function of the Pit Wizard’s Profile Software is where you will
be able to edit and customize Profile 4 of the Cyclone and it’s
parameters. You can work in the Edit Profile mode at any time, you
do not need to have the Cyclone connected to the Pit Wizard.
1. Press the {MODE} button on the Pit Wizard until you reach the
Edit Profile mode. The display will read:
2 Edit Profile
Edit Profile refers to editing the version of Profile 4 that is currently active
in the Pit Wizard’s Profile Software.
2. Press the {ENTER} button to display the first of the available
parameters:
21 Neutral
Use the {UP} and {DOWN} buttons to scroll through and display
the available user-adjustable parameters.
“21” indicates that you are on sub-screen one of menu item two.
3. Press the {ENTER} button to display the current parameter value.
Note: Neutral, Full Throttle, and Full Brake parameters should
not be modified for typical applications.
•One example for changing these parameters would be for Drag Racing,
where a shorter trigger throw may be desirable in order to reach Full
Drive faster by pulling the trigger a shorter distance. You would do this
by decreasing the value for Full Throttle (Figure 11).
4. Use the {UP} or {DOWN} buttons to change the parameter value:
21 Neutral
1498
µ
S
(CONT.)
